5 2007-000074 R237 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000084 R238 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R239 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R240 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000078 R241 R-CHIP 1Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R242 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000077 R243 R-CHIP 470ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R244 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R247 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R400 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R401 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000078 R402 R-CHIP 1Kohm,5%,1/10W,TP,1608 SA
5 2007-000821 R403 R-CHIP 390ohm,1%,1/10W,TP,1608 SA
5 2007-000070 R502 R-CHIP 0ohm,5%,1/10W,TP,1608 SA
5 2007-000070 R503 R-CHIP 0ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R600 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R602 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R603 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R604 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2801-003773 X400 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP SA
5 0403-001411 ZD100 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD101 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD102 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD103 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD104 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD200 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
2 BN90-00486D - ASSY STAND MJ17BS/GS17VT/GS17MS,EDC SNA
3 BN96-01063A STD ASSY STAND P-SIMPLE MJ15/17ASBS,ABS HB,BK07 SNA
4 6003-000269 STD SCREW-TAPTITE BH,+,S,M3,L6,ZPC(YEL),SWRCH18A SNA
4 6003-001086 STD SCREW-TAPTITE BH,+,B,M3,L12,ZPC(BLK),SWRCH18A SNA
4 BN61-00822A STD STAND-BRKT HINGE GS17VS,SECC,T1.2 SNA
4 BN61-00825A STD STAND-FRONT GS17VS,ABS HB,BK07 SNA
4 BN61-00826A STD STAND-REAR GS17VS,ABS HB,BK07 SNA
4 BN96-01061A STD ASSY MISC P-HINGE MJ15-17AS/BS,ZNDC2 SNA
2 BN90-00640L - ASSY COVER FRONT MJ15AS SNA
3 6003-001086 C/F+C/R SCREW-TAPTITE BH,+,B,M3,L12,ZPC(BLK),SWRCH18A SNA
3 BN96-01052B C/F ASSY COVER P-FRONT MJ15*S,ABS HB,GR70,SILVER SPRAY SNA
4 6003-000282 C/F SCREW-TAPTITE BH,+,B,M3,L8,ZPC(BLK),SWCH10 SNA
4 BN63-01206A C/F COVER-FRONT MJ15*S,ABS HB,GR70,SILVER SNA
4 BN64-00257A C/F KNOB-FUNCTION MJ17AS/BS,ABS+PC,HB,GR70 SNA
4 BN67-00120A C/F LENS-LED MATISSE,ACRYL,CLEAR SA
4 BN96-01111A C/F ASSY BOARD P-FUNCTION MATISSE,FUNCTION SNA
2 BN90-00641E - ASSY COVER REAR MJ15AS SNA
3 6003-000337 C/R+STD SCREW-TAPTITE BH,+,S,M4,L10,ZPC(BLK),SWRCH18 SNA
3 BN96-01053B C/R ASSY COVER P-REAR MJ15*S,ABS HB,BK07 SNA
4 BN61-00379A C/R BRACKET-STAND VESA GOYA153S,SECC,T2.0,,,, SNA
4 BN63-01207B C/R COVER-REAR MJ15AS,ABS HB,BK07,NONE,1.5 -
2 BN91-00403W - ASSY LCD-E27 MJ15BS SNA
3 BN07-00164A LCD LCD-PANEL LTM150XO-L01,Matisse,6 BIT,326.5*253.5*12,16.2M,40,0.297*0.297,0~50,3.3V,TN SNA
2 BN91-00784U - ASSY CHASSIS GY17HS SA
3 BN44-00107B CIS IP BOARD DAC-12M001B,MT15,4.5mA,8.0mA,48KHZ,2,90V/264VAC,+13V/+5V,0 to +40,-20 to +60,50/ SNA
3 BN61-01068A CIS BRACKET-PCB MJ15AS,SECC,T1.0 SNA
7 Electrical Parts List
MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS* 7-3
Level Loc. No. Code No. Description Specification Remarks
