Instructions for the Installer
11
3.2 Burner and Nozzle Data Tables (50-60 cm Models)
Burner
Rated
heat
capacity
(kW)
BOTTLED GAS – G30/G31 30/37 mbar
Nozzle
diameter
1/100 mm
By-pass
mm
1/100
Reduced heat
capacity
(W)
Flow-rate
g/h G30
Flow-rate
g/h G31
Auxiliary
1.0
50
30
350
73 71
Semi-rapid
1.75
65
33
450
127 125
Rapid (3)
3.0
85
45
800
218 214
Rapid (5)
2.3
75
45
800
167 164
Triple Flame
3.2
91
65
1500
233 229
Oven
3.2
87
48
850
233 229
Grill
3.0
87
//
//
218 214
Burner
Rated
heat
capacity
(kW)
TOWN GAS – G110 8 mbar
Nozzle
Diameter 1/100 mm
Reduced heat capacity
(W)
Auxiliary
1.0
145
350
Semi-rapid
1.75
185
450
Rapid (3)
3.0
260
800
Rapid (5)
2.3
220
800
Triple Flame
3.3
290
1200
Oven
3.2
270
850
The data for town gas refer to category III 1a2H3+ appliances.
Burner
Rated
heat
capacity
(kW)
NATURAL GAS - G20 20 mbar
Nozzle
Diameter 1/100 mm
Reduced heat capacity
(W)
Auxiliary
1.0
72
350
Semi-rapid
1.75
97
450
Rapid (3)
3.0
115
800
Rapid (5)
2.3
103
800
Triple Flame
3.5
133
1500
Oven
3.2
130
850
Grill
3.0
130
//
