Samsung C01 User Manual

Page 26

SiPTel C01 IP Phone User Manual

STEP 2

Select ‘YES’ to select DHCP, and press ‘OK’ button.

Use left arrow button from navigation keys to select ‘YES’ option and

press OK key.

STEP 3

After a while you’ll be able to see the following screen

Use left arrow button from the navigation key to select YES and

press OK button to reboot the IP Phone.

4.4.2.1.3. PPPoE (ADSL) User

If you are a PPPoE / ADSL user, please go through the following setup, with the required user-id and

password in hand to configure on SiPTel IP Phone.

STEP 1

Select ‘3: PPPoE’ to setup PPPoE / ADSL related parameters from ‘NETWORK MODE’

under ‘SETUP’ menu.

Press 3 or select ‘3: PPPoE using navigation keys and press OK

key.

STEP 2

Enter the username / ID given by your ISP as ADSL ID.

Enter the User ID for ADSL / PPPoE given by your ISP.

Select DHCP?

YES

Reboot system?

YES

2: DHCP

3:PPPoE

1: PPPoE ID
XXXXXXX
