Samsung C01 - Manual (Page 24)

SiPTel C01 IP Phone User Manual
4.4.2.1.1. Static IP User
If you are a static IP user, select this menu and setup the static related settings required for using the
SiPTel IP Phone.
STEP 1 Select ‘1: LAN (Static)’ in menu selection.
Press 1 or select ‘1: LAN (Static)’ using navigation keys and press
OK key.
STEP 2 Enter the IP address for the SiPTel IP Phone. You can use * to get a dot between octets.
Enter the IP Address given by the ISP and press OK key.
Ex: To enter 61.54.235.53 you would key in
61*54*235*53
STEP 3 Enter the Subnet Mask
Enter the Subnet Mask given by the ISP and press OK key.
Ex: To enter 255.255.255.0, you would key in
255*255*255*0
STEP 4 Enter the Gateway IP address
Enter the Gateway IP Address given by the ISP and press OK key.
Ex: To enter 61.54.235.254, you would key in
61*54*235*254
?
1:IP
61.54.235.53
1:LAN(Static)
2:DHCP
2: Subnet Mask
255.255.255.0
3: Gateway
61.54.235.254
