4. How to set daily ON/OFF repeat timer

(Example) To start operation at 7:10 am. and stop the air conditioner
at 11:00 am.

• The ON/OFF combination timer uses the current time as the

reference, and it is activated starting from whichever set time
comes first.

• With the ON/OFF combination timer, the settings are repeated

every day.

• You can check the timer ON/OFF times after you have set them by

pressing the ON TIME and OFF TIME setting buttons.

To cancel a timer program
• Press the CANCEL button.
• When either an ON or OFF timer is to be canceled, press the

button corresponding to the timer whose program is to be
canceled, and then press the CANCEL button.

• The airflow direction, fan speed and temperature setting can be

changed after a timer program has been set even when the unit is
stopped. Even when operation is stopped during an ON timer
program, the unit will start operating when the set time is reached
provided that the program is not canceled.

• When the ON timer and OFF timer are set to the same time, the

timer operates as if it is turned off.

USING THE 1-HOUR OFF
TIMER

1. 1-Hour OFF Timer

This function causes the unit to operate for one hour and then
stop, regardless of whether the unit is on or off when this
button is pressed.
The

indicator in the display indicates that this function is

operating.

Setting procedure:
Regardless of whether the unit is operating or stopped, press the 1
HR. TIMER button.

appears in the display.

Cancellation procedure:
Press the ON/OFF operation button to turn the unit off, wait for the
unit to stop operating, and then press the ON/OFF operation button
again.
The 1-Hour Timer function is now cancelled and the unit operates
normally.

• If, while the 1-Hour Timer function is operating, the 1HR. TIMER

button is pressed once to cancel the function and then again, the
unit continues to operate for one hour from that point in time and
then stops.

• It is not possible to use the OFF Timer and 1-Hour OFF Timer

together. Whichever function is set last takes precedence. If the 1
HR. TIMER button is pressed while the TIMER OFF function
operates, the OFF Timer is cancelled and the unit will stop
operating one hour later.

2. Operation together with the daily ON/OFF

repeat timer

The 1-Hour OFF Timer setting is given priority over the DAILY ON/
OFF REPEAT setting.

TIPS FOR ENERGY SAVING

Do not

• Block the air intake and outlet of the unit. If they are

obstructed, the unit will not work well, and may be damaged.

• Let direct sunlight into the room. Use sunshades, blinds or curtains.

If the walls and ceiling of the room are warmed by the sun, it will
take longer to cool the room.

• Always try to keep the air filter clean. (Refer to “CARE AND

CLEANING”.) A clogged filter will impair the performance of the
unit.

• To prevent conditioned air from escaping, keep windows, doors and

any other openings closed.

Operation

Indication

Set the timer ON/OFF times
as shown in 2-1, 2, 3 and 3-1,
2, 3.

The present time 10:30 pm. and

are displayed.

7:10 am.
ON

11:00 am.
OFF

10:30 pm.
Present time

NOTE

OI-149-14-EG
