QUICKIE 2 LITE PAGE 99
AUTOFOLD FOOTREST ASSM
Pos. Item Number Description Remarks
2 054853-001 FOOTPLATE SIZE 1 12" wide
2 054853-002 FOOTPLATE SIZE 2 13-14" wide
2 054853-003 FOOTPLATE SIZE 3 15-16" wide
2 054853-004 FOOTPLATE SIZE 4 17-18" wide
2 054853-005 FOOTPLATE SIZE 5 19-20" wide
3 054852 SPRING LEAF FOOTREST
4 230510 M6-25 FH C/S BLK
5A 107097 WELDMENT TUBE FOOTREST STD Short
5B 107098 WELDMENT TUBE FOOTREST LNG Long
6 107362 LOCKWASHER HIGH COLLAR M6
7 102263-001 SHCS M6X1X16 FULL NP
8 740130 LEG STRAP 10"-14" BLK 12-14" wide
8 740131 LEG STRAP 15"-17" BLK 15-17" wide
8 740132 LEG STRAP 18"-20" BLK 18-20" wide
12 104160 BUSHING FOOTREST
1-4 102830-001 ASSY FOOTPLATE AUTOFOLD 12W 12 wide
1-4 102830-002 ASSY FOOTPLATE AUTOFOLD 13W 13 wide
1-4 102830-003 ASSY FOOTPLATE AUTOFOLD 14W 14 wide
1-4 102830-004 ASSY FOOTPLATE AUTOFOLD 15W 15 wide
1-4 102830-005 ASSY FOOTPLATE AUTOFOLD 16W 16 wide
