PAGE 20 QUICKIE 2 LITE
CASTER PIN LOCKS
Note: Caster Pin Locks will not adapt to Short Wide Forks.
Pos. Item Number Description Remarks
1A 052310-001 BLOCK ASSY CSTR PIN LCK R STD Right Std Stem
1A 052311-001 BLOCK ASSY CSTR PIN LCK L STD Left Std Stem
1B 052310-002 BLOCK ASSY CSTR PIN LCK R+.5 Right +.5" Stem
1B 052311-002 BLOCK ASSY CSTR PIN LCK L +.5 Left +.5" Stem
1C 052310-003 BLOCK ASSY CSTR PIN LOCK R+1 Right +1" Stem
1C 052311-003 BLOCK ASSY CSTR PIN LCK +1 Left +1" Stem
2 050047 PLATE CASTER LOCK ANG ADJ
3 050050 KEY CASTER LOCK ANG ADJ
4 050053 SADDLE 17.8MM OD 8MM HOLE
5 050133 SHOULDER SCREW 8MMOD X 35MM LG
6 107204 YOKE CASTER PIN LOCK
7 102261 FHCS M5 X 12 INORGANIC
1A,2-7 107622 CSTR PIN LOCK R STD ASSM Right Std Stem
1B,2-7 107623 CSTR PIN LOCK R +.5 ASSM Right +.5" Stem
1C,2-7 107624 CSTR PIN LOCK R +1 ASSM Right +1" Stem
1A,2-7 107625 CSTR PIN LOCK L STD ASSM Left Std Stem
1B,2-7 107626 CSTR PIN LOCK L +.5 ASSM Left +.5" Stem
1C,2-7 107627 CSTR PIN LOCK L +1 ASSM Left +1" Stem
