QUICKIE 2 LITE PAGE 97
TUBULAR SIDE LATCH FOOTREST ASSM
Pos. Item Number Description Remarks
2 230132 SHCS M4 X .7 X 10
3 050129-002 LOCKWASHER HIGH COLLAR M4
4 052289 BUTTON LEVER LATCH
5 100837 SPRING COMP .25OD X 1.0LG
6 052103 LATCH PLUNGER FOOTREST
7 100842 ASSY LATCH PIVOT FOOTREST
8A 107097 WELDMENT TUBE FOOTREST STD Short
8B 107098 WELDMENT TUBE FOOTREST LNG Long
9 102263-001 SHCS M6X1X16 FULL NP
10 107362 LOCKWASHER HIGH COLLAR M6
11 052022 CLEVIS PIVOT TUBE
12 052282 PIN PIVOT FOOTREST
13 262133 WASHER LOCK M6
14 013147 BHCS M6X1X12MM BLK
18 104160 BUSHING FOOTREST
19 740130 LEG STRAP 10"-14" BLK
19 740131 LEG STRAP 15"-17" BLK
19 740132 LEG STRAP 18"-20" BLK
1-6 100830-010 ASSY TUBE FRST TBLR W-CVR 12W 12 wide
1-6 100830-011 ASSY TUBE FRST TBLR W-CVR 13W 13 wide
1-6 100830-012 ASSY TUBE FRST TBLR W-CVR 14W 14 wide
1-6 100830-013 ASSY TUBE FRST TBLR W-CVR 15W 15 wide
