Sunrise Medical Wheelchair Quickie 2 Lite - Manual (Page 7)

[08/2008]
QUICKIE 2 LITE PAGE 7
REAR SIDE FRAME
Pos. Item Number Description Remarks
2 106935 NUT NYLOCK THIN 1/4-28 ROHS
3 106944 WASHER FLAT THIN AN 1/4 ROHS
4 561087 TUBE SADDLE
5 104037 BACKREST GUSSET Q
6 106962 BHCS 1/4-28 X 1-3/4 ROHS
7 107353 1/4-20 X 1 BH C/S
8,9 107486 SEAT RAIL SADDLE KIT
10 104666 WEAR PAD FRAME ASSY
12 104414 WAVE WASHER 6 MM INORG
13 561018 1" TUBE END BUSHING THICK
7,11,12 107494 RETAINING PLUG KIT (4) Set of 4
1A-13 107492 REAR SDE FRM ASSM STD BCK R STANDARD BACK-Right
1A-13 107585 REAR SDE FRM ASSM STD BCK L STANDARD BACK-Left
1B-13 107493 REAR SDE FRM ASSM ANG BCK R ANGLE ADJUSTABLE BACK-Right
1B-13 107586 REAR SDE FRM ASSM ANG BCK L ANGLE ADJUSTABLE BACK-Left
