8. Appendix B: LUFP7 Gateway GSD File
; Supported baudrates
9.6_supp = 1
19.2_supp = 1
45.45_supp = 1
93.75_supp = 1
187.5_supp = 1
500_supp = 1
1.5M_supp = 1
3M_supp = 1
6M_supp = 1
12M_supp = 1
Communication rates supported by the
LUFP7 gateway.
All rates should be mentioned in this
section. The gateway supports all the
baud rates of the Profibus-DP networks.
; Maximum responder time for supported baudrates
MaxTsdr_9.6 = 60
MaxTsdr_19.2 = 60
MaxTsdr_45.45 = 60
MaxTsdr_93.75 = 60
MaxTsdr_187.5 = 60
MaxTsdr_500 = 100
MaxTsdr_1.5M = 150
MaxTsdr_3M = 250
MaxTsdr_6M = 450
MaxTsdr_12M = 800
Maximum response time of the gateway,
depending on the baud rate of the
Profibus-DP network.
The response times specified for the
gateway are standard values, compatible
with the TSX
PBY 100 coupler, for
example.
; Supported hardware features
Redundancy = 0 ; not supported
Repeater_Ctrl_Sig = 2 ; TTL
24V_Pins = 0 ; not connected
Implementation_Type = "SPC3"
General hardware characteristics specific
to Profibus-DP.
; Supported DP features
Freeze_Mode_supp = 1 ; supported
Sync_Mode_supp = 1 ; supported
Auto_Baud_supp = 1 ; supported
Set_Slave_Add_supp = 0 ; not supported
Supported and not supported Profibus-DP
services.
; Maximum polling frequency
Min_Slave_Intervall = 1 ; 100 us
Maximum polling frequency / Minimum
polling interval
100 µs is the smallest interval that can be
configured.
; Maximum supported sizes
Modular_Station = 1 ; modular
Max_Module = 24
Max_Input_Len = 244
Max_Output_Len = 244
Max_Data_Len = 416
Modul_Offset = 1
The LUFP7 gateway is a modular
Profibus-DP device, i.e. the size of its I/O
exchanges on the Profibus-DP network is
configured by combining several modules
together (see below).
Fail_Safe = 0 ; state CLEAR not accepted
Slave_Family = 0
Max_Diag_Data_Len = 6
Supported and not supported Profibus-DP
services (cont'd).
The length of the gateway's diagnostic data
should remain equal to 6. N.B. there are no
parameter data (the “
User_Prm_Data_Len ”
and “ User_Prm_Data ” parameters are
therefore omitted).
Bitmap_Device = "LUFP7_R"
Bitmap_Diag = "LUFP7_D"
Bitmap_SF = "LUFP7_S"
Names of the bitmap files used by SyCon
to display the gateway's connection
status.
; Definition of modules
Beginning of the section where the
modules used for configuring the sizes of
the gateway inputs and outputs are
defined.
