COMPLETE PARTS LIST
Item No. Description Qty. Part No.
306 Switch Plate 1
307 Pedal 2
308 Toe Cap 2
309 Pedal Soft Cushion 2
310 Pedal Bushing Cover-Left 2
311 Pedal Bushing Cover-Right 2
312 Console Housing - Upper 1
313 Console Housing – Bottom 1
314 Console Plastic Cover 1
315 Rubber Strip-4 4
316 Rubber Strip-3 4
317 Rubber Strip-2 4
318 Rear Shroud Plug-1 2
319 Rear Shroud Plug-2 2
320 Rubber Strip-1 4
321 Cable Plug 2
322 Incline Transmission Tube Holder 1
323 Moving Linkage Bushing 4
324 Control Board Cover 1
325 Pedal Swing Arm Cap 2
326 Taper Fixing Insert 35
327 Support Lump 1
328 Oblong Cushion 2
329 Circular Cushion 2
330 Rubber Cushion – Front 2
331 Rubber Cushion – Rear 2
332 Fixing Insert 22
333 Fixing Insert-Metal Inside 7
336 Action Handlebar Bar Front Cover 4
337 Action Handlebar Bar Cover 2
338 Elbow-Left 2
339 Elbow-Right 2
340 Button 1
341 Taper Fixing Insert-Metal Inside 3
