COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
434
Pedal Arm Support Axle
2
435
Crank Axle Bushing
2
436
M10 C Clip
6
437
M12 C Clip
2
438
M42 C Clip
2
439
10 x 18 x T1.0 Fiber Washer
2
440
15 x 8 x T2.0 Spring Washer
11
441
10 x 16 x T2.0 Spring Washer
7
442
20 x 6 x T2.0 Washer
3
443
32 x 6 x T2.0 Washer
1
444
35 x 14 x T2.0 Washer
2
445
10 x 18 x T5.1 Washer
4
446
M3 x 8mm Screw
2
447
M3 x 10mm Screw
18
448
4 x 12mm Screw
47
449
M2 x 6mm Screw
8
450
4 x 12mm Screw
23
451
M32 C Clip
2
452
M4 x 45mm Screw
2
453
M4 x 8mm Screw
4
454
7 x 12 - M5 x 5mm Pin Nut
4
456
10 x 23 x T2.0 Washer
4
457
6 x 10 x 1 Spring Washer
2
458
28.6 x 35.5 Bushing
2
459
12 x 20 x 0.5 Washer
2
460
12 x 20 x 2 PU Washer
2
500
501
12 x 62 - M10 x 20mm Bolt
2
502
20 x 78 - M14 x 35mm Bolt
2
503
M5 x 8mm Screw
2
504
M8 x 20mm Allen Head Bolt
8
505
M8 x 40mm Allen Head Bolt
2
506
M8 x 65mm Allen Head Bolt
2
507
M10 x 20mm Allen Head Bolt
4
508
M10 x 62mm Allen Head Bolt
1
