ENFORCER Delayed Egress Timer
2 SECO-LARM U.S.A., Inc.
Remote Alarm Relay Output ......................... 8
Lock Relay Output ........................................ 8
Local Alarm Output ....................................... 8
Pre-Delay Bypass Input ................................ 8
Free Egress Input ......................................... 9
Reset Input .................................................... 9
Initiate Input .................................................. 9
Bypass Input ................................................. 9
Lock Status Input .......................................... 9
Power Input ................................................... 9
Sample Applications .............................. 10-11
Troubleshooting .......................................... 12
Warranty ..................................................... 12
 3 Relock modes to meet different installation requirements:
 Standard manual relocking.
 BOCA (Building Officials Code Administrators) relocking.
 Timed relocking (1~60 seconds).
 Programmable nuisance delay timer (0~3 seconds).
 Adjustable pre-delay timer (1~30 seconds).
 Adjustable post-delay timer (1~60 seconds).
 Selectable manual or automatic relocking after power loss.
 Lock relay output (Form C, 10A@24VDC).
 Remote alarm relay output (Form C, 10A@24VDC).
 Local alarm output (transistor ground, 500mA@12VDC).
 Door status input.
 Status LEDs show relay status.
 Bypass input immediately releases locks.
 Free egress input allows easy egress during the day.
Features:
Specifications:
Table of Contents:
Operating voltage 12~24 VAC/VDC
Current draw
Standby 1 120mA@12VDC
Pre-delay 90mA@12VDC
Local alarm 35mA@12VDC
Timer module only 2 15mA@12VDC
Lock control output 10A@24VDC, Form C, NO/NC/COM
Remote alarm output 10A@24VDC, Form C, NO/NC/COM
Local alarm output Transistor ground, 500mA@12VDC
Features ........................................................ 2
Specifications ................................................ 2
Dimensions.................................................... 3
Overview ....................................................... 3
Installation ..................................................... 4
Wiring Diagram.............................................. 4
Relock Modes................................................ 5
Adjusting the Pre-Delay and Post-Delay ....... 6
Setting the Power-Up Mode and
Nuisance Delay ............................................. 6
Lock Status Jumper....................................... 7
Security Mode Jumper .................................. 7
Local Alarm Output Type Jumper.................. 7
1 Lock relay and remote alarm relay are normally energized.
2 When lock relay and remote alarm relay are de-energized.
