Specifications – Sony Blu-Ray Disc / DVD Home Theater System BDV-N790W User Manual
Page 58
58
US
Specifications
Amplifier Section
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both
channels driven, from 180
Hz - 20 kHz; rated 50 watts
per channel minimum
RMS power, with no more
than 1% total harmonic
distortion from 250 milli
watts to rated output.
POWER OUTPUT (reference)
Front L/Front R:
125 W (per channel at
3 ohms, 1 kHz)
Center:
250 W (at 6 ohms, 1 kHz)
Subwoofer:
250 W (at 6 ohms, 80 Hz)
Inputs (Analog)
AUDIO (AUDIO IN)
Sensitivity: 3.0 V/1.0 V
Inputs (Digital)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM
2CH (up to 48 kHz), Dolby
Digital, DTS
HDMI (IN 1)/HDMI (IN 2)
Supported formats: LPCM
5.1CH (up to 48 kHz),
LPCM 2CH (up to 96
kHz), Dolby Digital, DTS
Video Section
Outputs
VIDEO: 1 Vp-p 75 ohms
HDMI Section
Connector
Type A (19pin)
BD/DVD/Super Audio CD/CD System
Signal format system
NTSC
USB Section
USB 1/2 port:
Type A (For connecting
USB memory, memory
card reader, digital still
camera, and digital video
camera)
LAN Section
LAN (100) terminal
100BASE-TX Terminal
Wireless LAN Section
Blu-ray Disc/DVD receiver (HBD-N790W)
Standards Compliance
IEEE 802.11 b/g/n
Frequency and Channel
2.4 GHz - 2.4835 GHz
[CH1 -11]
FM Tuner Section
System
PLL quartz-locked digital
synthesizer
Tuning range
87.5 MHz - 108.0 MHz
(100 kHz step)
Antenna (aerial)
FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Speakers
Front (SS-TSB112)
Dimensions (approx.)
98 mm × 318 mm × 103
mm (3
7
/
8
in × 12
1
/
2
in ×
4
1
/
8
in) (w/h/d)
Mass (approx.)
0.7 kg (1 lb 9 oz)
Surround (SS-TSB111)
Dimensions (approx.)
98 mm × 255 mm × 91 mm
(3
7
/
8
in × 10 in × 3
5
/
8
in)
(w/h/d)
Mass (approx.)
0.6 kg (1 lb 6 oz)
Center (SS-CTB111)
Dimensions (approx.)
331 mm × 59 mm × 57 mm
(13
1
/
8
in × 2
3
/
8
in × 2
1
/
4
in) (w/h/d)
Mass (approx.)
0.5 kg (1 lb 2 oz)
Subwoofer (SS-WSB111)
Dimensions (approx.)
191 mm × 326 mm × 376
mm (7
1
/
2
in × 12
3
/
4
in ×
14
3
/
4
in) (w/h/d)
Mass (approx.)
5.6 kg (12 lb 6 oz)
General
Power requirements
120 V AC, 60 Hz
Power consumption
On: 115 W
Standby: 0.3 W (at the
Power Saving mode)
Dimensions (approx.)
460 mm × 74 mm × 226
mm (18
1
/
8
in × 3 in × 9 in)
(w/h/d) incl. projecting
parts
460 mm × 74 mm × 239
mm (18
1
/
8
in × 3 in ×
9
1
/
2
in) (w/h/d) (with the
wireless transceiver
inserted)
Mass (approx.)
3.6 kg (7 lb 15 oz)
