Page 91
91
GB
D:\CANNES\SONY_HA\JOB 2007\STR-
DG910\IM_910_CEL\Data_CEL\GB_data\GB06OTH_STR-DG910-CEL.fm
masterpage: Right
STR-DG910
3-094-430-31 (1)
Ad
dit
ion
al I
n
fo
rmatio
n
2)
Reference power output for front, center, surround
and surround back speakers. Depending on the
sound field settings and the source, there may be
no sound output.
3)
Measured under the following conditions:
220 V AC, 60 Hz
Frequency response
Analog
10 Hz – 70 kHz,
+0.5/–2 dB (with sound
field and equalizer
bypassed)
Input
Analog
Sensitivity: 500 mV/
50 kohms
S/N
4)
: 96 dB
(A, 500 mV
5)
)
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Output (Analog)
AUDIO OUT
Voltage: 500 mV/
10 kohms
SUB WOOFER
Voltage: 2 V/1 kohm
Equalizer
Gain levels
±10 dB, 0.5 dB step
4)
INPUT SHORT (with sound field and equalizer
bypassed).
5)
Weighted network, input level.
FM tuner section
Tuning range
87.5 – 108.0 MHz
Antenna
FM wire antenna
Antenna terminals
75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Antenna
Loop antenna
Intermediate frequency
450 kHz
6)
You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. While holding down TUNING
MODE, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the
procedure.
Video section
Inputs/Outputs
Video:
1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
: 0.7 Vp-p, 75 ohms
P
R
/C
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
General
Power requirements
Power output (DIGITAL MEDIA PORT)
DC OUT:
5V, 700 mA
Power consumption
Power consumption (during standby mode)
0.3 W (When
“CONTROL” in VIDEO
menu is set to “CTRL
OFF”.)
AC outlet (Models of area code
E2 only)
1 switched, 100 W/
0.4 A MAX
Dimensions (width/height/depth) (Approx.)
430 Ч 157.5 Ч 351.5 mm
including projecting parts
and controls
Area code
Tuning
scale
10 kHz step 9 kHz step
CEL, CEK, TW, KR
–
531
–
1,602
kHz
E2
530
–
1,610
kHz
6)
531
–
1,602
kHz
6)
Area code
Power requirements
CEL, CEK
230 V AC, 50/60 Hz
E2
120/220/240 V AC,
50/60 Hz
TW
110 V AC, 60 Hz
KR
220
–
230 V AC, 50/60 Hz
Area code
Power consumption
CEL, CEK, KR
230 W
E2
270 W
TW
650 W
continued
