1
Confirm the measurement
result.
When the measurement ends, a beep
sounds and the measurement result
appears on the display.
2
Press RECEIVER and then
press
V/v repeatedly to select
the item. Then, press .
3
Save the measurement result.
Select “SAVE” in step 2.
The measurement results are saved and
you can select the calibration type in the
A. CAL menu.
For details on calibration type, see page
38.
Tip
The size of a speaker (LARGE/SMALL) is
determined by the low frequency characteristics.
The measurement results may vary, depending on
the position of the optimizer microphone and
speakers, and the shape of the room. It is
recommended that you follow the measurement
results. However, you can change those settings in
the SYSTEM menu (page 47). Save the
measurement results first, then try to change the
settings if you want.
When error codes appear
Try the remedies and perform the Auto
Calibration again.
Confirming/saving the
measurement results
Measurement
result Display Explanation
When the
measurement
process
completes
properly
SAVE Proceed to step
2.
When the
measurement
process fails
ERROR
XXXX
See “When
error codes
appear” (page
36).
Item Explanation
RETRY Performs the Auto
Calibration again.
SAVE Saves the measurement
results and exits the setting
process.
WARN CHK Displays warning
concerning the
measurement results. See
“When you select “WARN
CHK”” (page 37).
PHASE Displays the phase of each
speaker (in phase/out of
phase). See “When you
select “PHASE”” (page 37).
DISTANCE Displays the measurement
result for speaker distance.
LEVEL Displays the measurement
result for speaker level.
EXIT Exits the setting process
without saving the
measurement results.
Error code Cause and remedies
ERROR 31 The SPEAKERS (OFF/A/B/
A+B) is set to off. Set it to others
and perform the Auto Calibration
again.
ERROR 32 None of the speakers were
detected. Make sure that the
optimizer microphone is
connected properly and perform
the Auto Calibration again.
If the optimizer microphone is
connected properly but the error
code appears, the optimizer
microphone cable may be
damaged or improperly
connected.
ERROR F 33 • None of the front speakers are
connected or only one front
speaker is connected.
• The optimizer microphone is
not connected.
