Introduction – Samsung SNC-C6225 User Manual
Page 12
12 – 10x Network Mini Smart Dome Camera
introduction
SNC-C7225
❖
Dome Cover
Do not remove the protection vinyl from dome cover
before fi nishing all installation process to protect dome
cover from scratches or dust.
Sun Shield Housing
Lockup Screw
Fixes main unit brackets like surface, wall, and ceiling.
•
•
•
Cabling Terminal Block
During installation, Power, Video, Communication,
Alarm Input cables are connected on to this cabling
terminal block.
DIP Switch
Adjusts camera ID and protocols.
•
•
Main Unit / Sun Shield Housing
Back of Main Unit
Sun Shield Housing
Main Body
Lockup Screw
Dome Cover
Cabling Terminal
Block
DIP Switch
