ENGLISH
61
• Each time these buttons are pressed, “ ” is moved
to the corresponding channel.
Note :
• Depending on the speaker settings and surround
mode, etc., some channels cannot be selected.
• You can adjust the current channel levels as desired. These adjusted levels are just memorized, not into preset
memory.
• Each time these buttons are pressed, the channel
level can be adjusted within the range of -15~+15
dB.
Press the CURSOR UP( )/DOWN( )
buttons to select the desired channel.
2
Repeat the above steps and to adjust each channel level until the sound level of each speaker
is heard to be equally loud.
4
Press the CURSOR LEFT( )/RIGHT( )
buttons to adjust the level of the selected
channel as desired.
3
STANDBY POWER ON
MAIN PAGE FAV
MUTE
CH. SET
VOL
RETURN
DISP
MI
OSD/MENU
1 STEREO
CH/ ADJUST
2 3
4 5 6
7 8 9
0 ENT
M2 M3
DSP DECODE DSP
RNC-510
STANDBY POWER ON
MAIN PAGE FAV
MUTE
CH. SET
VOL
RETURN
DISP
MI
OSD/MENU
1 STEREO
CH/ ADJUST
2 3
4 5 6
7 8 9
0 ENT
M2 M3
DSP DECODE DSP
• You can memorize the current channel levels into preset memory with performing “When selecting the PRESET
1 or PRESET 2 ” procedure on the previous page.
Press the CURSOR UP( )/DOWN( ) buttons to select the CH LEVEL TRIM, then press the
ENTER button.
1
Preform the steps ~ in “When selecting the PRESET 1 TRIM or PRESET 2 TRIM” procedure on
the previous page.
2
When selecting the CHANNEL LEVEL TRIM
STANDBY POWER ON
MAIN PAGE FAV
MUTE
CH. SET
VOL
RETURN
DISP
MI
OSD/MENU
1 STEREO
CH/ ADJUST
2 3
4 5 6
7 8 9
0 ENT
M2 M3
DSP DECODE DSP
RNC-510
C H L E V E L T R I M
R E T U R N : B a c k , : S e l e c t
F L : - - - - - - - - - - - - : 0 dB
C : - - - - - - - - - - - - : 0 dB
F R : - - - - - - - - - - - - : 0 dB
S R : - - - - - - - - - - - - : 0 dB
B R : - - - - - - - - - - - - : 0 dB
B L : - - - - - - - - - - - - : 0 dB
S L : - - - - - - - - - - - - : 0 dB
S W : - - - - - - - - - - - - : 0 dB
