Smooth Fitness DMT X2 User Manual
Page 7
www.smoothfitness.com
7
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
226
Crank
2
X2N-226
227
Crank Disk
1
X2N-227
228
Crank Disk Oval Cap
2
X2N-228
229
Crank Axle Bushing
2
X2N-229
230
Bearing 6005
2
X2N-230
231
Crank Disk Axle
1
X2N-231
232
Bearing Holder
1
X2N-232
233
Belt
1
X2N-233
234
Level Adjuster
2
X2N-234
236
Speed Sensor Base
1
X2N-236
237
Overlay
1
X2N-237
238
Speaker Bracket
1
X2N-238
241
10x94 – M12x22mm Bolt
1
X2N-241
242
Magnet
2
X2N-242
243
Compression Spring
1
X2N-243
300
301
Console Housing - Upper
1
X2N-301
302
Console Side Cover
2
X2N-302
303
Fan Cover – Top
1
X2N-303
304
Fan Cover – Bottom
1
X2N-304
305
Vane Adjustment Block
1
X2N-305
306
Fan Holder Ring
2
X2N-306
307
Console Housing – Bottom
1
X2N-307
311
Pivot Cap
2
X2N-311
312
Pivot Arm Bottom Cover – Left
1
X2N-312
313
Pivot Arm Bottom Cover – Right
1
X2N-313
314
iPod Dock Cover – Top
1
X2N-314
315
Action Handlebar Cover – LL
1
X2N-315
316
Action Handlebar Cover – LR
1
X2N-316
317
Action Handlebar Cover – RL
1
X2N-317
318
Action Handlebar Cover – RR
1
X2N-318
319
Switch Plate
1
X2N-319
320
Pedal Soft Cushion
2
X2N-320
321
Pedal
2
X2N-321
322
Rubber Cushion – Front
2
X2N-322
323
Rubber Cushion – Rear
2
X2N-323
324
Pedal Bushing Cover
4
X2N-324
325
Pedal Arm Cover – Top
2
X2N-325
326
Pedal Arm Cover – Bottom
2
X2N-326
327
Crank Disk Cover
2
X2N-327
328
Crank Cover
2
X2N-328
