504 x4 – Smooth Fitness DMT X2 User Manual
Page 21
www.smoothfitness.com
21
ASSEMBLY
STEP 3: Assemble the Console Support Tube
(A) Assemble the Console Support Tube (101) to the Main Frame and
secure using four M8x16mm Allen Head CAP Bolts (504) by 6mm Allen
Key
(B) Connect the 4Pin Power Wire – Middle (602) to the 4Pin Power Wire –
Lower (603).
504
X4
504
112
101
101
112
B
504
602
603
112
101
