SMOOTH AGILE DMT X2
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
100
101
Console Support Tube
1
X2N-101
102
Action Handlebar – Left
1
X2N-102
103
Action Handlebar – Right
1
X2N-103
104
Moving Linkage – Left
1
X2N-104
105
Moving Linkage – Right
1
X2N-105
106
Pedal Arm – Left
1
X2N-106
107
Pedal Arm – Right
1
X2N-107
108
Pedal Swing Arm
2
X2N-108
109
Incline Frame
1
X2N-109
110
Incline Transmission Tube-Front
1
X2N-110
111
Incline Transmission Tube-Back
1
X2N-111
112
Main Frame
1
X2N-112
113
Cover Support Tube
1
X2N-113
115
Tension Wheel Bracket
1
X2N-115
116
Pedal Support Base
2
X2N-116
117
Pedal Buffer Set
2
X2N-117
121
Magnet Bracket
1
X2N-121
122
Motor Bracket
1
X2N-122
200
201
Handlebar Foam Grip
2
X2N-201
202
Handlebar Cap
2
X2N-202
203
Hand Pulse Sensor Back Cover
2
X2N-203
204
Hand Pulse Sensor Cover
2
X2N-204
206
Incline Frame Holder – Rear
2
X2N-206
210
Bearing 6004
4
X2N-210
211
Bearing 2201
2
X2N-211
212
Bearing 608zz
8
X2N-212
213
Moving Linkage Bushing
4
X2N-213
214
Bearing 6804
4
X2N-214
215
Bearing 2203
2
X2N-215
216
Pedal Fixing Base
2
X2N-216
217
Bearing 6205
4
X2N-217
218
Bushing 25.6x28.6x50mm
2
X2N-218
219
Bushing 16x22.2x10.7mm
4
X2N-219
220
Bushing 18x12mm
2
X2N-220
221
Flywheel Pivot
1
X2N-221
222
Bearing 6003
2
X2N-222
223
Aluminum Disk
1
X2N-223
224
Flywheel
1
X2N-224
225
Bearing 6300
2
X2N-225
