701 x4, 501 x4 – Smooth Fitness DMT X2 User Manual
Page 28
28
SMOOTH AGILE DMT X2
ASSEMBLY
STEP 10: Assemble the Action Handlebar Lower Cover
(A) Assemble the Action Handlebar Lower Cover (701) to the Action
Handlebar – Right (103) and secure using the 4x12mm Screw – Cone Point
(501)
(B) Repeat the above procedure to assemble the left side.
701
X4
501
X4
501
701
103 701
105
501
