SMOOTH AGILE DMT X2
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
465
M5x16mm Screw
2
X2N-465
466
M4x10mm Screw
4
X2N-466
467
M5x15mm Screw
1
X2N-467
468
M5 Nut
2
X2N-468
469
5mm Lock Washer
1
X2N-469
470
12x18x1.5mm Plastic Washer
2
X2N-470
471
3x12mm Screw
2
X2N-471
476
M3x10mm Screw – Cone Point
2
X2N-476
478
M5x5mm Bolt
1
X2N-478
479
M3 Nut
2
X2N-479
480
3x5x1mm Washer
4
X2N-480
500
501
4x12mm Screw – Cone Point
4
X2N-501
502
15x22 – M8x10mm Bolt
2
X2N-502
503
15x26 – M8x15mm Bolt
2
X2N-503
504
M8x16mm Allen Head CAP Bolt
4
X2N-504
505
20x78 – M14x35mm Bolt
2
X2N-505
506
4x12mm Screw – Flat Point
6
X2N-506
507
M10x56mm Allen Head Bolt
1
X2N-507
508
M10 Nylon Nut
1
X2N-508
509
4x19mm Screw
3
X2N-509
510
4.5x15mm Screw
6
X2N-510
511
M10x40mm Allen Head CAP Bolt
4
X2N-511
513
8x27x2mm Washer
2
X2N-513
514
8x14xT2.0mm Spring Washer
2
X2N-514
515
M8x20mm Allen Head Bolt
2
X2N-515
516
M5x6mm Screw
2
X2N-516
517
10x16xT2.0mm Spring Washer
4
X2N-517
518
M5x12mm Screw
2
X2N-518
520
8x27x1mm Plastic Washer
2
X2N-520
521
20.7x29.1x0.3mm Wave Washer
2
X2N-521
600
601
4Pin Power Wire – Upper
1
X2N-601
602
4Pin Power Wire – Middle
1
X2N-602
603
4Pin Power Wire – Lower
1
X2N-603
604
6Pin Motor Connection Wire
1
X2N-604
605
Power Connection Wire
3
X2N-605
606
3C Power Wire
1
X2N-606
607
Hand Pulse Sensor Wire – Upper
2
X2N-607
608
Hand Pulse Sensor Wire – Middle
2
X2N-608
609
Hand Pulse Sensor Wire – Lower
2
X2N-609
610
PC Board
1
X2N-610
611
6Pin Control Board Connection Wire
1
X2N-611
612
Receiver Wire
1
X2N-612
