62 Cheetah 15K.5 SCSI Product Manual, Rev. J
Figure 16. Nonshielded 68-pin SCSI device connector used on LW drives
.0787
(2.00)
.519
(13.18)
.315
(8.00)
3.650
(92.71)
.840 – .005
(21.34)
.315 – .010
(8.00)
+.001
—.002
dia .083
(2.1)
Trifurcated Pins
(4 places)
.085
(2.16)
x 45¡ chamfer
typ
.20
(5.08)
typ
.60
(15.24)
.100
(2.54)
Pos.
1
Pos.
2
1 2 3 4
1.816
(46.13) Position 1
Pos. 68
Pos. 35
1.650
(41.91)
.980
(24.89)
1.368
(37.74)
.767
(19.48)
.050
(1.27) .218
(5.54)
Pos.
1
.022
.050
.020 .047
.0787 .200
1.650 .3937 .600
.346
3.650–.005
.270
.155
