34 Cheetah 15K.5 SCSI Product Manual, Rev. J
Figure 9. LC mounting configuration dimensions
J H
L
B
A
S
K
[1]
M C
R REF
F
[1]
D
E
P
Mounting holes are 6-32 UNC 2B, three
on each side and four on the bottom.
Max screw penetration into side of drive
is 0.15 in. (3.81 mm). Max screw
tightening torque is 6.0 in-lb (3.32 nm)
with minimum full thread engagement of
0.12 in. (3.05 mm).
Notes:
[1]
Inches
A
B
C
D
E
F
H
J
K
L
M
N
P
R
S
T
U
26.10
147.00
101.60
95.25
3.18
44.45
28.50
101.60
6.35
41.60
4.60
1.02
41.28
66.50
7.00
0.38
0.38
1.028
5.787
4.000
3.750
.125
1.750
1.122
4.000
.250
1.638
.181
.040
1.625
2.618
.276
.015
.015
max
max
± .010
± .010
± .010
± .010
± .020
± .010
± .010
± .010
± .020
max
max
max
max
± .25
± .25
± .25
± .25
± .50
± .25
± .25
± .25
± .50
max
max
Dimension Table
Millimeters
-X- U
-Z- -X- N
-Z- T //
-Z-
-Z-
-X-
REF
