MVS-8000SF
12. CNI-9 board (Suffix : -12) (MKS-8110HD)
CNI-9 board A side/Component side
S101 (A-3), S201, S301 (B-3), S401, S501 (C-3), S601 (D-3), S701, S801 (E-3), S901 (F-3),
S1001, S1101 (G-3), S1201 (H-3), S1301, S1401 (J-3), S1501, S1601 (K-3), S1701 (L-3) :
Output band-width compensation switch
They are the output band-width compensation ON/OFF switches.
Use these switches in the factory setting positions.
Factory setting
S101 to S1701 : All OFF
S101 S301 S201 S401 S501 S601 S801 S901 S1101 S1001 S1201 S1301 S1401 S1501 S1601 S1701
1
2
3
4
A B C D E F G H J K L
S701
