C-1
A
PPENDIX
C
S
PECIFICATIONS
Physical Characteristics
Ports
48 10BASE-T/100BASE-TX, with auto-negotiation
2 slots for optional dual-port 100BASE-FX or single-port
1000BASE-SX media expansion modules
Network Interface
10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3, 4, 5)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5)
Ports 1-48: RJ-45 connectors, fixed crossover
100BASE-FX: SC connector
Multimode fiber cable; 62.5/125 or 50/125 microns
1000BASE-SX: SC connector
Multimode fiber cable; 62.5/125 or 50/125 microns
Buffer Architecture
128 Kbytes per 10/100 Mbps ports
2 Mbytes per 1000 Mbps ports
Aggregate Bandwidth
13.6 Gbps
Switching Database
12K MAC address entries
LEDs
System: Power, RDP, Mgmt
Port: Mode (flow control, full duplex, activity),
Link (speed, link, disable/partition)
