-7-
M1051 6" Bench Grinder
SET
UP
The SHOP FOX ® Model M1051 has been carefully pack-
aged for safe transporting. If you notice the machine has
been damaged, please contact Woodstock International
Technical Support at 1-360-734-3482 or send e-mail to:
[email protected]
Unpacking
SET UP
Inventory
NOTICE
If ordering replacement parts, refer to
the parts list and diagram in the back of
the manual.
The following is a description of the main components
shipped with the SHOP FOX ® Model M1051. You should
lay the components out to easily identify them.
Box Contents:
A. Eye Shield ................................................. 2
B. Spark Breaker ............................................. 2
C. Phlp Hd Scr M5-.8 X 45 ................................. 2
D. Flat Washer 5mm ........................................ 2
E. Flat Washer 5mm ......................................... 2
F. Lock Washer 5mm ........................................ 2
G. Phlp Hd Scr M5-.8 X 8 .................................... 2
H. Lock Washer 5mm ........................................ 2
I. Hex Nut M5-0.8 ........................................... 2
J. Grinding Wheel 30 Grit .................................. 1
K. Grinding Wheel 60 Grit .................................. 1
L. Flat Washer 8mm ......................................... 4
M. Lock Washer 8mm ........................................ 4
N. Hex Bolt M8-1.25 X 12 ................................... 4
O. Right-hand Tool Rest ..................................... 1
Left-hand Tool Rest (Not Shown) ...................... 1
P. 6" Bench Grinder Unit (Not Shown) .................... 1
Should any part be missing, examine the packaging
carefully to be sure those parts are not among the
packing materials. If any parts are missing, find the
part number in the back of this manual and contact
Woodstock International, Inc. at 360-734-3482 or at
[email protected]
A
K
J
I
H
G
F
E
D
C
B
O
N
M
L
Figure 3. Inventory.
