53
Ref. Part
No. Number Description
HYDRAULIC PUMP ASSEMBLY
1 HG 70516 Housing Kit
2 HG 70573 End Cap Kit
3 HG 50641 Straight Headless Pin
4 HG 50969 Hex Flange Bolt, M8-1.25 x 60mm
5 HG 51232 Housing O-Ring
6 HG 2513027 Charge Pump Kit
7 HG 50273 Gerotor Assembly
8 HG 9004101-1340 O-Ring
9 HG 50095 Socket Head Screw, M6 x 1.0-20mm
10 HG 2513030 Bypass Valve Kit
11 HG 70521 Pumpshaft Kit
12 HG 50315 Ball Bearing, 17 x 40 x 12
13 HG 51161 Lip Seal
14 HG 50329 Retaining Ring
15 HG 50951 Spacer
16 HG 70331 Cylinder Block Kit
17 HG 2003014 Block Spring
18 HG 2003017 Block Thrust Washer
19 HG 51444 Valve Plate
20 HG 2003087 Swash Plate
21 HG 50551 Ball Thrust Bearing
22 HG 2003005 Trunnion Arm
23 HG 2000015 Slot Guide
24 HG 2510062 Check Valve Kit (.024” Orfice) port “A” on Left Hand Pump, port “B” on Right Hand Pump
25 HG 70403 Charge Relief Kit
26 HG 2513043 Trunnion Seal with Retainer
27 HG 9005110-4400 Straight Thread Plug
28 HG 50408 Straight Headless Pin
29 HG 70525 Overhaul Seal Kit
