29
36"A DECK FRAME
Ref. Part
No.
No. Description
1 461170 Belt Cover With Decal
2 481625-01 Knob With Stud
3 04029-03 Knob, Deck Cover Mounting
4 48100-08 Bushing, Caster
5 461790 Frame Weldment, Deck Mounting - 36" (Includes Item #28)
6 04062-04 Hair Pin Cotter, .177" x 3-1/4"
7 48114-04 Grease Fitting Str. 1/4-28 Self Tap
8 04066-01 Quick Pin, .438" Dia.
9 04024-02 Nut, Push-On - 3/8" Dia.
10 04041-07 Flatwasher, 3/8" (.391 x .938 x .105)
11 04019-04 Nut, 3/8-16 Serrated Flange Hex Head
12 45325 Yoke, Caster Wheel
13 04001-80 Capscrew, Hex Head 1/2-13 x 6-1/2"
14 04021-07 Locknut, 1/2-13 Elastic Stop
15 481843 Wheel Assembly, Caster
16 481845 Tire, 11 x 4.00-5
17 481770 Retainer
18 481846 Roller Bearing
19 481844 Rim, 5.0" x 2.75" (Includes #20 & 23)
20 48114-05 Grease Fitting Str. 1/4-28
21 481769 Roller Bearing .625 x 3.25"
22 04001-46 Capscrew, Hex Head 3/8-16 x 2-1/4"
23 * Tire Valve, Purchase Locally
24 43511 Sleeve, Caster Wheel
25 04040-10 Flatwasher, 5/8" - (.688 x 1.75 x .134)
26 04017-36 Capscrew, 1/2-13 x 1" Serrated Flange Hex Head
27 04112-05 Nut, 1/2-13 Spiralock
28 04110-03 U-Nut, 3/8-16
