Scag Power Equipment SWZU User Manual
Page 31
27
1
461785
Cutter Deck W/ Decals
x
461786*
Cutter Deck W/ Decals (small frame)
x
461787*
Cutter Deck W/ Decals (large frame)
x
461788
Cutter Deck W/ Decals
x
2
04017-27
Capscrew, 3/8-16 x 1" Serr. Flng.
x
x
x
3
04021-05
Lock Nut, 3/8-16 Center Lock
x
x
x
4
48100-15
Bushing, .376" ID Oilite
x
x
x
5
481632
Wheel, Anti-Scalp
x
x
x
6
422478
Bracket, Anti-Scalp Wheel
x
x
x
7
04003-26
Bolt, Carriage 3/8-16 x 4"
x
x
x
8
04021-09
Hex Nut, 3/8-16 Elastic Stop
x
x
x
9
04043-04
Flatwasher, 3/8" (.938 x .391 x .105)
x
x
x
10
48224
Ball Bearings
x
x
x
11
04110-03
U-Nut, 3/8-16
x
x
x
12
43660
Pivot, Idler
x
x
x
13
48542
Rod End, Male 1/2-20 RH Thread
x
x
x
14
482416
Pulley, Idler
x
x
x
15
461755
Push Arm - LH (Incl. 13, 19 & 49)
x
x
x
16
461766
Push Arm - RH (Incl. 13, 19 & 49)
x
x
x
17
04001-136 Capscrew, Hex Head 3/8-16 x 1-1/2" x
x
x
18
04019-04
Nut, 3/8-16 Serrated Flange
x
x
x
19
04020-08
Nut, 1/2-20 Jam
x
x
x
20
481838
Pin Assembly (Incl. 21 & 23)
x
x
x
21
04020-25
Nut, 3/8-24 Jam
x
x
x
22
43512
Spacer, Deck Adjustment Pin
x
x
x
23
481539
Rod End, Male 3/8-24
x
x
x
24
461663
Spindle Assembly
x
x
x
25
43590
Spacer, Spindle
x
x
x
26
04001-41
Bolt,Hex Head 5/8-11 x 9-1/2"
x
x
x
27
04043-06
Flatwasher, 5/8 W
x
x
x
28
481706
Cutter Blade 16-1/2"
x
28
481707
Cutter Blade 18"
x
28
481708
Cutter Blade 21"
x
28A
481710
Cutter Blade 16-1/2" Hi Lift
x
28A
481711
Cutter Blade 18" Hi Lift
x
28A
481712
Cutter Blade 21" Hi Lift
x
29
04001-176 Bolt, Hex Head 5/16-18 x 1-3/4" Gr 8
x
x
x
30
43589
Spindle Shaft
x
x
x
31
481024
Seal, Cutter Spindle - Top
x
x
x
32
481022
Tapered Bearings (Two)
x
x
x
33
48114-04
Grease Fitting
x
x
x
34
43644
Spindle Housing
x
x
x
35
48677
Relief Fitting, Cutter Spindle
x
x
x
36
43312
Spacer Outside
x
x
x
37
43296
Spacer, Inside
x
x
x
38
481025
Seal, Cutter Spindle - Bottom
x
x
x
39
43297
Spindle Bushing
x
x
x
40
481035
Nut, Spindle
x
x
x
41
481625-01 Wing Nut, 3/8-16
x
x
x
42
451118
Roller Shaft (small frame)
x
x
45944
Roller Shaft (large frame)
x
x
43
04001-09
Bolt, Hex Head 5/16-18 x 1"
x
x
x
44
04021-22
Hex Nut, 5/16-18 Elastic Stop Gr. 8
x
x
x
45
04030-03
Lock Washer 5/16"
x
x
x
46
48926
Tapered Hub
x
x
x
47
48038
Guide, Roller
x
x
x
48
482744
Pulley, 5.75 O.D.
x
x
48A
482745
Puley, 6.35 O.D.
x
49
481104-08 Grease Fitting, 90 Degree
x
x
x
50
482281
Belt, Deck Drive
x
483012
Belt, Deck Drive
x
483011
Belt, Deck Drive
x
Ref.
Part
No.
No.
Description
48 52 61
48"A, 52"A & 61"A CUTTER DECKS
51
04001-74
Bolt, Hex Head 1/2-13 x 3"
x
x
x
52
04020-09
Hex Nut, 5/8-11
x
x
x
53
04021-07
Hex Nut, 1/2-13 Elastic Stop
x
54
422745
Belt Cover, RH
x
x
422911
Belt Cover, RH
x
55
04003-23
Bolt, Carriage 3/8-16 x 1"
x
x
x
56
461632
Idler Arm Weldment (Incl. Item 10)
x
x
x
57
04001-54
Capscrew, Hex Head 3/8-16 x 3"
x
x
x
58
461295
Discharge Chute
x
x
461296
Discharge Chute
x
59
04019-03
Nut, 5/16-18 Serrated Flange
x
x
x
60
482797
Spring, Deck Idler
x
x
x
61
04001-154 Bolt, Hex Head 5/16-18 x 4-1/4"
x
x
x
62
482245
Spring, Chute Return
x
x
x
63
04021-09
Nut, 3/8-16 Elastic Stop
x
x
x
64
423786
Baffle Weldment 48A
x
64A
423803
Baffle Weldment 52A
x
64B
423792
Baffle Weldment 61A
x
65
04001-31
Bolt, Hex Head 3/8-16 x 2-1/2"
x
x
x
66
04063-08
Key, 1/4" x 1/4" x 2"
x
x
x
67
482783
Pulley, Idler
x
x
x
68
451724
Push Arm Shaft
x
x
x
69
422744
Belt Cover LH
x
x
422910
Belt Cover LH
x
70
04021-10
Hex Nut, 5/16-18 Elastic Stop
x
x
x
71
04001-172 Bolt, Hex Head 1/4-20 x 1" Gr. 8
x
x
x
72
04001-11
Bolt, Hex Head 5/16-18 x 1-1/2"
x
x
x
73
04001-12
Bolt, Hex Head 5/16-18 x 1-3/4"
x
x
x
Ref. Part
No.
No.
Description
48 52 61
* Measure the engine deck to determine frame size. 461786 is for small frame (16") & 461787 is for large frame (20")
