52"A & 61"A - DECK FRAME (*LARGE FRAME)
1 461280 Belt Cover With Decals x
461281 Belt Cover With Decals x
2 481625-01 Knob With Stud x x
3 04029-03 Knob, Deck Cover Mounting x x
4 48100-08 Bushing, Caster x x
5 461793 Frame Weldment, Deck Mounting (Includes Item #27) x
461794 Frame Weldment, Deck Mounting (Includes Item #27) x
6 48114-04 Grease Fitting Str. 1/4-28 Self Tap x x
7 04066-01 Quick Pin, .438" Dia. x x
8 04024-02 Nut, Push-On - 3/8" Dia. x x
9 04041-07 Flatwasher, 3/8" (.391 x .938 x .105) x x
10 04019-04 Nut, 3/8-16 Serrated Flange Hex Head x x
11 45325 Yoke, Caster Wheel x x
12 04001-80 Capscrew, Hex Head 1/2-13 x 6-1/2" x x
13 04021-07 Locknut, 1/2-13 Elastic Stop x x
14 481843 Wheel Assembly, Caster x x
15 481845 Tire, 11 x 4.00-5 x x
16 481770 Retainer x x
17 481846 Roller Bearing x x
18 481844 Rim, 5.0" x 2-3/4" (Incl. #19 & 21) x x
19 48114-05 Grease Fitting Str. 1/4-28 x x
20 481769 Roller Bearing .625 x 3.25" x x
21 ** Tire Valve, Purchase Locally x x
22 04062-04 Hair Pin Cotter, .177 x 3-1/4" x x
23 43511 Sleeve, Caster Wheel x x
24 04040-10 Flatwasher, 5/8" - (.688 x 1.75 x .134) x x
25 04017-36 Capscrew, 1/2-13 x 1" Serrated Flange Hex Head x x
26 04112-05 Nut, 1/2-13 Spiralock x x
27 04110-03 U-Nut, 3/8-16 x x
28 04001-46 Capscrew, Hex Head 3/8-16 x 2-1/4" x x
Ref. Part
No.
No. Description 52A 61A
* Measure the width of the engine deck to determine frame size. "Large Frame" is 20" wide.
