GALAXY GG/GX GXHA SERIES HOT WATER AND STEAM BOILER
Location and identification of parts
Figure 14.
Figure 15.
Figure 17.
Name and
Rating Plate
Lighting
Instructions
(inside front
panel)
Gas Valve
Burner
Access Door
Burners
Gas Manifold
Jacket Top
Relief Valve
Temperature
and Pressure
Gauge
Jacket Top
Pop Safety Valve Pressure Gauge
Front
Panel
4
Figure 16 GXHA Series—Steam Boiler
Jacket Top
Pop Safety Valve Pressure Gauge
Your gas boiler must be installed and serviced by a qualified service agency or
gas supplier. The lack of proper service can result in a dangerous condition.
See lighting instructions on page 8.
Easy access front panel on standard extended jacket, is removed
by simply pressing hand against panel and pushing up.
