Those 3 types are like the following:
1. Window Type
The selected area is displayed with a box. The motion can be detected for the area only. You can
manually set the motion detection area. You can use the UP/DOWN/LEFT/RIGHT Setup switch to
set the size. To move to POSITION, press the switch. After setting the position using the UP/DOWN/
LEFT/RIGHT Setup switch, press the Setup switch to move to the upper menu. To set the size and
position for AREA, select any of 0, 1, 2, and 3.
Note
The selected window for AREA is displayed in white and the unselected one is displayed in black.
. Label Type
The box-typed motion detection area is prefixed. The detected area is displayed with size and position
changing. You cannot change AREA because it is displayed with “---.”
