78
ITEM SYMBOL Hexadecimal Decimal FUNCTION
[66] ESC Y n1 n2 [1B,59,n1,n2,data] H Prints 8-pin double-speed double-density graphics
data [27,89,n1,n2,data] D (120 dpi). The total number of dots in the data is
set by n1 + n2 x 256.
[67] ESC Z n1 n2 [1B,5A,n1,n2,data] H Prints 8-pin quadruple-density graphics (240 dpi).
data [27,90,n1,n2,data] D The total number of dots in the data is set by
n1 + n2 x 256.
[68] ESC \ n1 n2 [1B,5C,n1,n2] H Sets relative dot position to the current position.
[27,92,n1,n2] D The dot pitch is 1/120 inch.
(For Example)
n1 + (n2
x 256)< 32768 (8000h), then move n1 + (n2 x 256) dots to the right.
n1 + (n2 x 256)
≥
32768, then move 65536 - {n1 +(n2 x 256)} dots to the
left from the current position.
[69] ESC ^ m n1 n2 [1B,5E,m,n1,n2,data] H Sets various 9 pin graphic mode.
data [27,94,m,n1,n2,data] D The total number of dots in the data is set by
(n1 + n2 x 256) x 2.
[70] ESC a n [1B,61,n] H [27,97,n] D Justification mode.
n=0 : left justification is set (default).
n=1 : centering is set.
n=2 : right justification is set.
n=3 : full justification is set.
When n is other than 0, the printer performs one
linefeed after printing.
[71] ESC b c n1 n2 [1B,62,c,n1,n2,...,n16,00] H Sets vertical tab position in channels beginning from
...n16 NUL [27,98,c,n1,n2,...,n16,0] D n1 and end with NUL [00]H as in ESC b command.
c specifies one of channels 0 to 7 to be set.
[72] ESC g [1B,67] H [27,103] D Selects 15 cpi mode.
[73] ESC j n [1B,6A,n] H [27,106,n] D n/216" reverse linefeed after printing (0
≤
n
≤
255).
This command is ignored in the cut sheet feeder mode.
m Graphic Type Number Maximum Horizontal
of Pins Columns Density
0 Standard-density 9 816 60
1 Double-density 9 1632 120
2 Double-speed double-density 9 1632 120
3 Quadruple-density 9 3264 240
4 80 dpi graphics 9 1088 80
5 72 dpi graphics 9 979 72
6 90 dpi graphics 9 1224 90
7 144 dpi graphics 8 1958 144
MSB
1st
byte 2nd
byte
MSB
2 bytes
B. Control code summary (FX)
