Looking at the controls

See pages in ( ) for more details.

The recorder

1 Battery compartment (at the bottom)

(25)

2 MODE button (17)
3 DISPLAY button (14, 19)
4 CLOCK SET button (at the bottom)

(16)

5 MIC SENS switch (at the bottom) (12)
6 AVLS switch (at the bottom) (18)
7 DC IN 6V jack (at the rear) (6)
8 Display window (14, 19)
9 SYNCHRO REC (synchro-recording)

switch (11)

0 MIC (PLUG IN POWER) jack (12)
!¡ LINE IN (OPTICAL) jack (6, 11)
!™ LINE OUT jack (20)
!£ DIGITAL MEGA BASS button (18)

!¢ 2 (headphones)/REMOTE jack (8)

!∞ REC indicator (14)
!§ Vertical jog dial (17, 23)
!¶ TITLE/ENTER button (23)
!• ( (play) button (7, 9)

!ª =/+ (search /AMS) button (7, 9)

@º p (stop) button (7, 9)

@¡ VOLUME +/– button (9)
@™ HOLD switch (20)
@£ ERASE button (21)
@¢ T MARK button (22)
@∞ END SEARCH button (7)
@§ REC (record) switch (7)
@¶ P (pause) button (7, 9)

@• OPEN button (6)

!∞

!§

!¶

!•
