14 Barracuda 9FC Installation Guide, Rev. A
Figure 2. Suggested air flow
Abbildung 2. Empfohlener Luftstromverlauf
Above unit
Under unit
Note. Air flows in the direction shown or
in reverse direction (side to side)
Above unit
Under unit
Note. Air flows in the direction shown (back to front)
or in reverse direction (front to back)
