ATA C OMMAND B LOCK AND S ET D ESCRIPTION SSD-D XXX (I)-4300 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
4300D-00DSR P AGE 66 F EBRUARY 27, 2009
Write DMA — CAh
The Write DMA command allows the host to write data using the DMA transfer
protocol.
Note:
This function does not apply to SiliconDrive IIs that have DMA
disabled.
Table 52: Write DMA — CAh
Register D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Feature X
Sector Count Sector Count
Sector Number Sector Number (LBA7-0)
Cylinder Low Cylinder Low(LBA15-8)
Cylinder High Cylinder High(LBA23-16)
Drive Head X LBA X Drive Head Number(LBA27-24)
Command CAh
