L IST OF F IGURES SSD-D XXX (I)-4300 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
4300D-00DSR P AGE VI F EBRUARY 27, 2009
L
IST OF
F
IGURES
Figure 1: Physical Dimensions......................................................................................... 1
Figure 2: Pin Locations .................................................................................................... 2
Figure 3: Jumper Settings................................................................................................ 2
Figure 4: True IDE PIO Mode Read/Write Access Timing Diagram .............................. 13
Figure 5: True IDE PIO Multiword DMA Read/Write Access Timing ............................. 15
Figure 6: Initiating a UDMA Data-In Burst...................................................................... 17
Figure 7: Sustained UDMA Data-In Burst ...................................................................... 18
Figure 8: Host Pausing a UDMA Data-In Burst.............................................................. 18
Figure 9: Device Terminating a UDMA Data-In Burst .................................................... 19
Figure 10: Host Terminating a UDMA Data-In Burst...................................................... 20
Figure 11: Initiating a UDMA Data-Out Burst................................................................. 21
Figure 12: Sustained UDMA Data-Out Burst ................................................................. 21
Figure 13: Device Pausing a UDMA Data-Out Burst ..................................................... 22
Figure 14: Host Terminating a UDMA Data-Out Burst................................................... 23
Figure 15: Device Terminating a UDMA Data-Out Burst ............................................... 24
Figure 16: Sample Label................................................................................................ 78
