ATA C OMMAND B LOCK AND S ET D ESCRIPTION SSD-D XXX (I)-4300 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
4300D-00DSR P AGE 53 F EBRUARY 27, 2009
Read Buffer — E4h
The Read Buffer command allows the host to read the contents of the sector
buffer. When issued, the device sets the BSY bit and sets up the sector buffer
data in preparation for the read operation. When the data is ready, the DRQ bit
is set and the BSY bit in the Status register are set and cleared, respectively.
Table 38: Read Buffer — E4h
Register D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Feature X
Sector Count X
Sector Number X
Cylinder Low X
Cylinder High X
Drive Head X X X Drive X
Command E4h
