The following table describes the SiliconDrive II 2.5" PATA Drive 44-pin IDE
connector signals.
Table 7: Pin Assignments
Pin
IDE-ATA
Ultra DMA
Pin
IDE-ATA
Ultra DMA
1
RESET#
RESET#
2
GND
GND
3
D7
D7
4
D8
D8
5
D6
D6
6
D9
D9
7
D5
D5
8
D10
D10
9
D4
D4
10
D11
D11
11
D3
D3
12
D12
D12
13
D2
D2
14
D13
D13
15
D1
D1
16
D14
D14
17
D0
D0
18
D15
D15
19
GND
GND
20
KEY
KEY
21
DMARQ
DMARQ#
22
GND
GND
23
IOWR#
STOP
24
GND
GND
25
IORD#
HDSTROBE
HDMARDY#
26
GND
GND
27
IORDY
DDSTROBE
DDMARDY#
28
CSEL#
CSEL#
29
DMACK#
DMACK#
30
GND
GND
31
INTRQ
INTRQ
32
IOCS16#
IOCS16#
33
A1
A1
34
PDIAG#
PDIAG#
35
A0
A0
36
A2
A2
37
CS0#
CS0#
38
CS1#
CS1#
39
DASP#
DASP
40
GND
GND
41
V
CC
V
CC
42
V
CC
V
CC
43
GND
GND
44
NC
NC
