ATA C OMMAND B LOCK AND S ET D ESCRIPTION SSD-D XXX (I)-4300 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
4300D-00DSR P AGE 52 F EBRUARY 27, 2009
Recalibrate — 1Xh
The Recalibrate command sets the cylinder low and high, head number to 0h,
and sector number to 1h in CHS mode. In LBA mode (i.e., LBA = 1), the sector
number is set to 0h.
Table 37: Recalibrate — 1Xh
Register D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Feature X
Sector Count X
Sector Number X
Cylinder Low X
Cylinder High X
Drive Head 1 LBA 1 Drive X
Command 1Xh
