SATO MB400I User Manual

Page 22

Reference

Dispense mode printing

Dispense mode printing setting

Changing the dispense mode printing setting

The dispenser operation mode setting is changed by the DIP switch (DSW) settings when the
power is turned on, and by button settings. The settings are enabled upon turning the power
off.

Type

Automatic
printing setting

Manual printing
setting

Operation

Prints one label after receiving data, then waits for label to
be peeled. After the label is peeled, the next label is
printed automatically.

Prints one label after receiving data, then enters offline
status. When the PRINT button is pressed, the next label is
printed. After the specified number of labels are printed,
printing is ended, and no labels are printed when the
PRINT button is pressed.

Default

Manual
printing
setting

Note:

When the buzzer sound mode is enabled, the buzzer sounds upon startup.
Release the PRINT/FEED button to stop the buzzer.
To end the dispenser operation mode setting, confirm that the STATUS LED is on in
green, then turn the power off. After changing the dispenser operation mode setting,
be sure to restore the DSW to their original settings.

Automatic dispenser printing setting

DSW-1,2,3,4=(OFF,OFF,OFF,ON) + cover open+ PRINT button + POWER

Manual dispenser printing setting

DSW-1,2,3,4=(OFF,OFF,OFF,ON) + cover open + FEED button + POWER

Processing dispenser operation mode setting

(STATUS LED flashes green)

Setting completes

(STATUS LED lights green)

Test printing mode (FEED button + POWER ON)

FEED
button

The LED display for the test printing mode is as follows.

Operation status

STATUS (LED)

Starting test printing mode

ON (orange)

Test printing initializing

Blinking (green)

Test printing

ON (green)

Stop printing

OFF

* When the buzzer sound mode is enabled, the buzzer sounds upon startup.

Release the FEED button to stop the buzzer.

POWER ON

Start test printing

Test printing

Stop printing

FEED button + POWER
