i n t e l l i g e n t w i r e l e s s p l a t f o r m
airClient™ Nexus PRO TOTAL User Guide
2.8. aCNPT Router/NAT Configuration
The aCNPT unit can also be configured in Router or NAT mode which behaves like Infrastructure mode.
The procedures for configuring the parameters in Router/NAT mode are given below. In this mode, the
units will associate with any access point.
Note: The configuration procedure of parameters in NAT mode is the same as for Router mode.
2.8.1. Ethernet Configuration
The Ethernet IP is configured during the operational mode change to aCNPT Router mode.
Follow these steps below if you need to re-configure the aCNPT Router Ethernet parameters:
1. From the ’Summary Information’ page, click on the ’Ethernet Configuration’ link to change
Ethernet parameters.
2. Enter the ‘IP address’ and ‘IP mask’.
3. Click on ‘Apply Changes’ to effect the changes.
Figure 2-15 aCNPT Router Ethernet Configuration
