JVC KD-DV7301 User Manual

Page 61

The following marks are used to indicate...

: Built-in CD player operations.

: External CD changer operations.

: External USB memory operations.

: Indicator displayed for the

corresponding operation.

How to use the M MODE button

If you press M MODE, the unit goes into functions mode,
then the number buttons and

∞

buttons work as

different function buttons.

Ex.: When number button 2 works as

MO (monaural) button.

To use these buttons for their original functions
again after pressing M MODE, wait for 5 seconds
without pressing any of these buttons until the
functions mode is cleared or press M MODE again.

Detaching the control panel

Attaching the control panel

CONTENTS

Control panel —

KD-G632/KD-G631

....... 4

Remote controller —

RM-RK50

........... 5

Getting started ................................ 6

Basic operations ................................................... 6

Radio operations ............................. 7

FM RDS operations ........................... 8

Searching for your favorite FM RDS programme ... 8

Disc / USB memory operations ........... 11

Playing a disc in the unit ..................................... 11
Playing discs in the CD changer ........................... 11
Playing from a USB memory ................................ 11

Sound adjustments .......................... 14

General settings — PSM .................. 15

DAB tuner operations ....................... 18

iPod/D. player operations ................. 19

Other external component operations ... 21

Maintenance ................................... 22

More about this unit ........................ 23

Troubleshooting .............................. 26

Specifications .................................. 29

For safety...

• Do not raise the volume level too much, as this will

block outside sounds, making driving dangerous.

• Stop the car before performing any complicated

operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.

Speci$ ca#ii

SEC!IUNEA AMPLIFICATORULUI AUDIO
Putere maxim% de ie"ire:

Fa#%/Spate:

50 W/canal

Putere continu% (RMS):

Fa#%/Spate:

19 W/canal la 4 \, 40 – 20 000 Hz, cu o distorsiune
armonicã totalã mai micã de 0,8^

Impedan#% de intrare:

4 \ (admisibil între 4 \ "i 8 \)

Gam% de control a
egalizatorului:

Frecven#e:

60 Hz, 150 Hz, 400 Hz, 1 kHz, 2,5 kHz, 6,3 kHz,
15 kHz

Nivel:

± 10 dB

Raport semnal/zgomot:

70 dB

Nivelul de ie"ire a
sunetului:

Digital (DIGITAL OUT:
optic%):

Lungimea undei de lucru: 660 nm
Nivel de ie"ire: între –21 dBm "i –15 dBm

Nivel ie"ire/impedan#%:

Sarcinã de 2,5 V/20 k\ (scarã completã)

Impedan#% de ie"ire:

1 k\

Nivel de ie"ire pentru difuzorul de bas/Impedan#% :

Sarcinã de 2,5 V/20 k\ (scarã completã)

Sistem de culori:

PAL

Ie"ire video (compus%):

1 Vp-p/75 \

Alte mufe:

Schimb%tor de CD-uri, intrare telecomand% volan, intrare LINE IN, a doua
ie"iri audio.

SEC!IUNEA RADIORECEPTORULUI
Interval de frecven#%:

FM:

87,5 MHz - 108,0 MHz

AM:

(UM) 522 kHz – 1.620 kHz
(UL) 144 kHz - 279 kHz

Radioreceptor FM:

Sensibilitate util%:

11,3 dBf (1,0 `V/75 \)

Prag de sensibilitate de
50 dB:

16,3 dBf (1,8 `V/75 \)

Selectare de canale
alternative (400 kHz):

65 dB

R%spuns în frecven#%:

40 Hz - 15 000 Hz

Separare stereo:

30 dB

Radioreceptor UM

Sensibilitate/
Selectivitate:

20 `V/35 dB

Radioreceptor UL

Sensibilitate:

50 `V

Continuare pe pagina urm!toare

REFERIN E
