14
EN
GETTING STARTED
MasterPage: Body_Left
This camera’s 2-way power supply system lets you
choose the most appropriate source of power. Do not use
provided power supply units with other equipment.
Charging the Battery Pack
1
Set the power switch to OFF while pressing down the
lock button located on the switch.
2
Slide and hold OPEN in the direction of the arrow A,
then open the battery/CF card cover.
3
Insert the battery pack firmly into the battery pack
mount until it locks into space as shown in the illustration.
4
Close the battery/CF card cover firmly until it locks.
5
Connect the AC adapter to the camera.
6
Plug the AC adapter into an AC outlet. The power/
charge lamp on the camera blinks to indicate charging
has started.
7
When the power/charge lamp goes out, charging is
finished. Unplug the AC adapter from the AC outlet.
Disconnect the AC adapter from the camera.
To detach the battery pack
Open the battery/CF card cover, and remove the battery
pack while sliding BATTERY in the direction of the arrow
B.
Power
To AC outlet
Power/Charge Lamp
Battery Pack
AC Adapter
Open the cover.
Power
Switch
To DC
connector
Lock Button
OPEN
Battery/CF Card Cover
Protrusion
Battery pack Charging time
BN-VM200U (provided) Approx. 1 hr. 35 min.
BATTERY
