E-11

DC12V

AC24V

Y/C OUT

SYNC IN

POWER

VIDEO OUT

SEE INST-

RUCTION

MANUAL

CLASS 2 ONL

Y(U

TYPE)

ISOLA

TED PO

WER ONL

TYPE)

AUX GND

⁄

)

ﬁ

›

(

‹

[DC 12V, AC 24V] Power input terminals
(TK-C1430E)
To input DC 12V or AC 24V power.

[TX+A, TX-B, RX+C, RX-D] Control
signal connection terminals
Terminals for inputting signals with
electrical characteristics conforming to
the EIA/TIA RS-422A or RS-485 standard.
੬

RX.TERM switch

[AUX, GND] Auxiliary Input/Output Terminals

If there is any change in the area set on the
MOTION DETECT screen, these terminals
output the corresponding signals. (

੬ Page 34)

These terminals also output the B&W/
COLOUR signal. (

੬ Page 30)

[Open-collector low signal. Maximum
voltage 30V, current 30mA.]
When carrying out B&W/COLOUR switching
using the control signal, the signals are input
through these terminals. (

੬ Page 30)

[B&W: make; COLOUR: break]

[Y/C OUT] Y/C output connector
This 4-pin connector outputs the luminance
and chrominance signal.
• Pin configuration of Y/C OUT connector

[VIDEO OUT] Video signal output
connector
This BNC connector outputs a composite
video signal. Connect this to the video input
connector of a video monitor, switcher, etc.

[POWER] Power indicator lamp
This lamp lights when power is supplied
to the camera.

[SYNC IN] Sync signal input connector
This BNC connector accepts the input of
an external sync signal such as a composite
video (VBS) or black burst (BB) signal.
When a sync signal is input into this
connector, the camera operation is
automatically synchronized with the
external sync signal.
To terminate this connector at 75Ω, turn
ON the EXT.TERM switch

Power cable (TK-C1431EG)
Connect to the commercial AC (220V –
240V) outlet.

Pin No.

Signal

GND

Luminance (Y)

Chrominance (C)

Y/C OUT

SYNC IN

POWER

VIDEO OUT

SEE INST-

RUCTION

MANUAL

AUX GND

ﬂ

)

ﬁ

›

‹

⁄

TK-C1430E

TK-C1431EG
