Available signals
The following signals are available for this monitor.
Video signals
No. Signal name
Signal format shown in
the status display
( ☞ page 11)
Input terminal
VIDEO
(INPUT1, INPUT2)
E. AUDIO HD/SD SDI
(IN 1, IN 2)* 1
DVI-D (HDCP)
(Digital component
/Digital RGB)
1 NTSC NTSC √ — —
2 PAL PAL √ — —
3 B/W50 B/W50 √ — —
4 B/W60 B/W60 √ — —
5 480/60i 480/60i — √ √
6 480/59.94i 480/59.94i — √ √
7 576/50i 576/50i — √ √
8 480/60p 480/60p — — √
9 480/59.94p 480/59.94p — — √
10 576/50p 576/50p — — √
11 640 *480/60p 640 *480/60p — — √
12 640 *480/59.94p 640 *480/59.94p — — √
13 720/60p 720/60p — √ √
14 720/59.94p 720/59.94p — √ √
15 720/50p 720/50p — √ √
16 720/30p 720/30p — √ —
17 720/29.97p 720/29.97p — √ —
18 720/25p 720/25p — √ —
19 720/24p 720/24p — √ —
20 720/23.98p 720/23.98p — √ —
21 1080/60i 1080/60i — √ √
22 1080/59.94i 1080/59.94i — √ √
23 1035/60i 1035/60i — √ √* 2
24 1035/59.94i 1035/59.94i — √ √* 3
25 1080/50i 1080/50i — √ √
26 1080/60p 1080/60p — — √
27 1080/59.94p 1080/59.94p — — √
28 1080/50p 1080/50p — — √
29 1080/30p 1080/30p — √ √
30 1080/29.97p 1080/29.97p — √ √
31 1080/25p 1080/25p — √ √
32 1080/24p 1080/24p — √ √
33 1080/23.98p 1080/23.98p — √ √
34 1080/30psF 1080/30psf — √* 2 —
35 1080/29.97psF 1080/29.97psf — √* 3 —
36 1080/24psF 1080/24psf — √ —
37 1080/23.98psF 1080/23.98psf — √ —
„
√: Acceptable
—: Not acceptable
* 1 Compatible with EMBEDDED AUDIO signals.
* 2 The signal is recognized as 1080/60i, and the status is displayed as “1080/60i.”
* 3 The signal is recognized as 1080/59.94i, and the status is displayed as “1080/59.94i.”
Specifi cations (cont.)
