15
EN
SYNC FUNCTION
Settings for the synchronization with signals
Item To do Setting value
NO SYNC ACTION Select the screen status when no signal is coming in.
P.SAVE: power save mode
GRAY B.: gray screen
OFF, P.SAVE, GRAY B.
DELAY TIME Select the period until the screen status changes as selected in “NO SYNC
ACTION” after signals stop coming in. 30sec., 5min., 15min.
LOW LATENCY Activates/deactivates the function to shorten the time taken to display the
picture (low latency function).
If the picture is not displayed steadily while “ON” is selected, select “OFF.”
While “ON” is selected, the displayed picture may become unstable when
an operation using buttons on the front panel or the menu is performed, or
when the signal format changes. •
•
ON, OFF
When setting “NO SYNC ACTION” to “GRAY B.,” the screen color changes to gray and the power consumption of the back light is saved by
half. Selecting “P.SAVE” (power save mode) saves more power consumption by turning off the back light.
SET-UP MENU
FUNCTION SETTING
Settings for the sub menu display, color system, color of the tally lamp, picture size, intensity of the button lamps and the PHASE adjustment.
Item To do Setting value
sub menu POSI. Select the contents and displaying position of “sub menu.”
The setting values and features are as follows.
LOWER1: Displays the current setting and adjustment bar at the lower part
of the screen.
UPPER1: Displays the current setting and adjustment bar at the upper
part of the screen.
LOWER2: Displays the current setting at the lower part of the screen.
UPPER2: Displays the current setting at the upper part of the screen.
The adjustment bar is not displayed for some items. •
LOWER1, UPPER1, LOWER2,
UPPER2
COLOR SYSTEM Select the color system.
If the picture is unstable with “AUTO,” select “NTSC” or “PAL.” •
AUTO, NTSC, PAL
TALLY SELECT Select the color of the tally lamp. GREEN, RED
DIMMER Select the intensity of the button lamps. NORMAL, DARK
COMPONENT PHASE Deactivates the function of PHASE adjustment (Picture adjustment knob
and “PICTURE SUB ADJ.” in SET-UP MENU) except when an NTSC signal
comes in (
☞ 3 on page 10).
ENABLE, DISABLE
COLOR GAMUT Setting for the color reproduction range. (DT-R24L4D only)
ITU-709: The monitor displays using a color gamut conforming to ITU-R
BT.709.
Adobe: The monitor displays using a color gamut suitable for Adobe RGB.
The coverage is about 98%.
ITU-709, Adobe
PICTURE SUB ADJ.
Adjusts the standard level for the picture adjustment and selects the set-up level for the input video signal.
Item To do Setting value
CONTRAST *1 Adjust the standard level for the contrast adjusted with the CONTRAST knob
on the front panel. –20 – +20
BRIGHT *1 Adjust the standard level for the brightness adjusted with the BRIGHT knob on
the front panel. –20 – +20
CHROMA *1 Adjust the standard level for the chroma adjusted with the CHROMA knob on
the front panel. –20 – +20
PHASE *1, *2 Adjust the standard level for the phase adjusted with the PHASE knob on the
front panel. –20 – +20
NTSC SETUP Select the set-up level of the input NTSC signal.
00: compliant with 0% set-up signal
7.5: compliant with 7.5% set-up signal
00, 7.5
sub menu Display the sub menu which enables you to adjust the items in “PICTURE SUB ADJ.” while viewing the actual
picture.
reset Restore the default settings for all the items in “PICTURE SUB ADJ.”
*1 Memorized for each input.
*2 When “COMPONENT PHASE” is set to “DISABLE” and an NTSC signal is input, PHASE can be adjusted.
•
„
