TM-H1950CG
1-15
No.51961
21
● To use the SWITCHED OUT terminal, the main power must be ON. (Unlike a bridged output, this connector outputs relocked
digital signals.)
● Signal output from the SWITCHED OUT terminal can be changed by selecting INPUT C (SDI 1) or INPUT D (SDI 2). You can
use the front panel buttons or do it via external control.
● When INPUT-A or INPUT-B is selected, this terminal outputs the signals last selected. In the standby mode, signals from the
SDI 1 connector are output.
APPENDIX: CONNECTION EXAMPLES FOR THE
SDI INPUT CARD
Pin No. Signal
1 GND (Y)
2 GND (C)
3 Y
4 C
Ⅵ Y/C (Mini DIN 4 pin) terminal
specification
IN
Y/C
OUT
2
1
2
1
4
3
4
3
22
